3 Axis CNC Machine Milling Drilling Vmc Machinery for Metal Processing

Basic Info

Model NO.	BF-1160V
After-sales Service	Provided
Warranty	One Year
Condition	New
Certification	CE, ISO9001
Customized	Non-Customized
Material	Metal
Application	Metal Cutting Machine, Metal Processing Machinery Parts, Metal Engraving Machinery
Product Name	Linear Guideway Vmc
Model	Bf-1160V
Weight	7000kg
Controller System	Simens 828d
Spindle Speed	12000rpm
Spindle Motor	15/18.5kw
Table Size	1200X600mm
Rapid Feed	30m/Min
Rotary Table	4 Axis / 5 Axis Optional
Transport Package	Wooden Box
Specification	3200x2810x3290mm
Trademark	Baofeng
Origin	China
HS Code	8457101000
Production Capacity	10000sets / Year

Product Description

Our Advantages

Works Show

Detailed Photos

Product Description

BF-1160V is designed with an ultra-rigid structure and X/Y/Z axis high precision linear guide and ball screw with locking preload design, which can provide you with fast, powerful, and stable machining performance, making it suitable for high precision parts machining and mold machining. It can be widely used in the automotive, machinery, instrumentation, light industrial textile, and electronic instrumentation industries, and can fully demonstrate high precision and high-efficiency machining capability at a very reasonable cost.

· The machine tool is of C-type structure, mainly composed of table, column, saddle, base, spindle box, hydraulic system, lubrication system, cooling, and filtering system, electric control system, and other components.· Adopt large span support, according to the principle of Bessel point physical deformation resistance, so that the casting to obtain the best deformation resistance structure. The body is designed by Finite Element Analysis(FEA) to ensure the stability and rigidity of the mechanism.
· With the use of a double-layer box structure design, the weight will be 20% more than the single-layer structure, while the stability of the body, resistance to deformation, and rigidity will be much higher than the ordinary single-layer structure. The foot of the base is designed to be tilted outward to make the base more stable.
· Adopt BBT40 direct spindle, compared with ordinary BT 40 spindle, the tool swing is smaller at high speed, tool vibration is smaller, the tool pulling force is stronger, and the combination of tool shank and the spindle is more rigid. Adopting ceramic bearing, it has better precision, rigidity, and finish than a steel ball bearing.The tapered surface and the end face of the BBT40 spindle can fit close to the tool holder at the same time, ensuring the required tool rigidity under heavy cutting conditions.Fitted with a short nose spindle, the tooltip position is further in from the spindle fixing point for more stable spindle machining and greater rigidity.The smaller the spindle vibration, the higher the surface processing quality, the more efficient tapping, and the longer tool life. The fastest tapping speed up to 6000 rpm, the smallest tooth can be tapped M1.0.

Product Parameters

Range	X-axis travel	mm	1150
	Y-axis travel	mm	650
	Z-axis travel	mm	650
	Spindle nose to table	mm	130-780
	Spindle center to column	mm	650
Table	Table Size (W×L)	mm	1200×600
	Table load	kg	800
	T slot	No.	5-18x100
Controller	Fanuc		0i-MF(1)
Spindle	Spindle transmission		Direct drive
	Spindle speed	rpm	12000
	Spindle taper		BBT40
	Spindle motor	kw	15/18.5 (S1/S2 30min)
	Spindle torque	Nm	95.5/118 (S1/S2 30min)
X/Y/Z axis	X/Y/Z motor	kw	4.0/7.0/4.0
	X/Y/Z motor torque	Nm	X/Z 22/64 Y 30/83
	X/Y/Z rapid feed rate	m/min	30/30/30
Accuracy	Positioning accuracy	mm	0.003/300
Accuracy	Repeated positioning	mm	0.002/300
Other	Dimension	mm	3200×2810×3290
	Weight	kg	7000

Standard Accessories

No.	Item
1	Spindle blowing system
2	Coolant cooling system
3	Automatic centralized lubrication system
4	Spindle temperature control system
5	Handle wheel
6	Heat exchanger for electrical cabinet
7	Rear chip-removal device
8	Guideway cover
9	Full enclosed cover
10	Alarming light
11	Working light

Optional Accessories

No.	Item	Yes / No	Remark
1	Tool magazine		BT40-24T
2	Chip conveyor
3	Oil mist collectors
4	Cylinder system

After Sales Service· Baofeng promises to be responsible for all machines from Baofeng, regardless of where they are purchased from, regardless of their age and can provide after-sales service for all machines confirmed as Baofeng.· All Baofeng machines are delivered with the company's after-sale number, and after-sale supervisor, design supervisor, and sales supervisor's mobile phone number to ensure that can be contacted us anytime. · Responsible for the quality of all Baofeng machines. Once the machine is found to have quality problems, we will do our best to solve them.· Provide 7*24 hours after-sales service and promise response in 4 hours. All machine tools maintenance only need to charge the cost of engineers travel. For all Baofeng machine tools, provide a free annual maintenance service.
